Affinity AVSJ15 Round Flange VSD Motor 1.5hp Full Rate 2.25 Uprate

Part # AVSJ15

US Motors: Affinity AVSJ15 - 1.5hp-2.25hp VSD (Variable Speed Drive) Motor

230 V / 50-60 Hz / 10 Amp / 1035-3450 RPM / 56J Frame / Round C Flange
Times and speeds can be programmed on top of speed drive, under weather protective cover.

Motor can be installed on the pumps: Hayward models Maxflow 1600series / Super 2600series, / Super2 3000series / Jandy Stealth (prior 2008) / Jacuzzi Magnum / any other Round Flange compatible pump housings
